Understanding Handwheel Preparation
The most important and variable consideration in handwheels is how the hub of the wheel is prepared and mated to the shaft of what it is driving. One of the most misunderstood parts of specing or buying industrial handwheels is the importance of understanding how to mount and retain them. Knowing the terms used in the industry and a general understanding of how they work will help cut one extra step you may have to take when asked about handwheels.
Section 1Wheel PreparationFree Preview
Square
Hexes
Half Circles
Screw Set
Different Hub Styles
Hub styles include squares, hexes and half circles with set screws to retain them. Some are pressed into place on splines that are part of the shaft. Some are threaded to be screwed into place, and some are welded.
SquareHexesHalf CirclesScrew SetSection 2Bore
Section 3Keyways Are Not A Bore
Lecture 3Keyways
Lecture 4Broaching
Final Quiz
